Ersatzlüfter-Set für MFA & Kuba Verdampfer inkl. Adapterplatte

This handy replacement fan set is the ideal solution when the original fan is defective or needs to be replaced. Instead of an often very expensive original part, you get a significantly cheaper and straightforward alternative.

The set consists of an SKL Compact Cooling Fan (model MTF601RF), 80 x 80 x 38 mm plus a precision-made adapter plate. The plate is specifically designed to securely mount the fan. The fan is screwed directly onto the plate.

Fan technical specifications:

• Brand: SKL, model MTF601RF
• Dimensions: 80 x 80 x 38 mm
• Voltage: AC 220–240 V, 50/60 Hz
• Power: 13 W (50 Hz) / 10 W (60 Hz)
• Speed: 2,400 RPM (50 Hz) / 2,900 RPM (60 Hz)
• Current draw: 0.09 A (50 Hz) / 0.07 A (60 Hz)
• Bearing type: Ball bearing
• Protection: Impedance protected
• Certification: RoHS compliant

Benefits:

• Significantly cheaper than an original fan
• Easy installation thanks to the precision-fit adapter plate
• Durable ball bearing for a long service life
• RoHS certified
• Suitable for selected MFA and Kuba evaporators

Included in delivery:

• 1 x adapter plate, 92 mm wide
• 1 x SKL Compact Cooling Fan MTF601RF, 80 x 80 x 38 mm
